Multiple Scan Modes:

• 17 blue laser crosses

• 7 parallel laser lines

• 1 extra blue laser line for deep hole scanning.

Laser Class: Class II (eye-safe)

Accuracy (ISO 17025): Up to 0.020mm

Resolution: 0.020mm

Scanning Rate: Up to 2.8 million measurements per second

Scanning Area: Up to 700mm x 600mm

Volumetric Accuracy:

• Standard 0.015mm + 0.035mm/m

• Paired with MSCAN-L15 0.015mm + 0.012mm/m

Stand-off Distance: 300mm

Depth of Field: 550mm

Operating Temperature: -10°C to 40°C

File Output: .stl, .ply, .obj, .asc, .igs, .txt

Connectivity: USB 3.0

Supported Software: DefinSight, ScanViewer, Metrolog X

Operating Systems: Windows(10, 11), Mac OS X

Unit Dimensions: 203mm x 80mm x 44mm

Unit Weight: 570 grams

• Calibration board

• Power cable and adaptor

• USB 3.0 cable

• 2000 6mm marker dots

• 1000 3mm marker dots

• USB dongle

• USB drive with user guide and DefinSight Software
